LN SF CBO 1200 V 32W ML 83040 U19

NEW

GTIN: 4099854894169 Folding box / 1 Show all packages

Download data sheet

Highly versatile due to selectable CCT and lumen steps (Multi Select) on the driver
Plug & Upgrade concept for easy conversion to sensor or emergency luminaire
Replacement of conventional T8 luminaires with up to 6200 lm
Good glare reduction (UGR < 19)

Values of type of protection, impact resistance and ambient temperature range may differ depending on the installation of the components.
All electrical connections must be made by a qualified person.
Caution, risk of electric shock.
Product in protection class I. All electrically conductive, metallic housing parts that can absorb voltage during operation or during maintenance in the event of a fault must be continuously connected to the protective earthing conductor.

Nominal wattage	32 W / 27 W / 21 W / 16 W
Nominal voltage	220…240 V
Mains frequency	50…60 Hz
Nominal current	153mA / 128mA / 106mA / 85 mA
Inrush current	13.79 A
Inrush current time T_h50	119 µs
Max. number of luminaires per miniature circuit breaker B16	48
Max. number of luminaires per miniature circuit breaker C10	36
Max. number of luminaires per miniature circuit breaker C16	58
Power factor λ	> 0.90
Total harmonic distortion	< 20 %
Protection class	I
Operating mode	Integrated LED driver

Luminous flux	4000 lm / 3370 lm / 2620 lm / 2000 lm
Luminous efficacy	125 lm/W
Color temperature	3000 K / 4000 K
Reference control setting of contained light source (Kelvin)	4000 K
Light color (designation)	Warm White; Cool White
Color rendering index Ra	> 80
Standard deviation of color matching	< 5 sdcm
Low flicker	Yes
Flickering metric (Pst LM)	< 1
Stroboscope effect metric (SVM)	< 0.4
Photobiological safety group acc. to EN62778	RG0
Beam angle	85 °
UGR	< 19

Nominal wattage	Color temperature	Luminous flux	Luminous efficacy
32 W	3000 K	4000 lm	125 lm/W
32 W	4000 K	4000 lm	125 lm/W
27 W	3000 K	3370 lm	125 lm/W
27 W	4000 K	3370 lm	125 lm/W
21 W	3000 K	2620 lm	125 lm/W
21 W	4000 K	2620 lm	125 lm/W
16 W	3000 K	2000 lm	125 lm/W
16 W	4000 K	2000 lm	125 lm/W

Product color	White
Housing color	White
RAL Color (most similar)	RAL 9003
Body material	Polycarbonate (PC)
Cover material	Polycarbonate (PC)
Light emitting surface material	Polycarbonate (PC)
Glow Wire Test according to IEC 60695-2-12	650 °C
Mercury content	0.0 mg

Ambient temperature range	-20…+40 °C
Temperature range at storage	-20…+80 °C
Type of connection	Screwless terminal, 3-POLE (L, N, PE)
Type of protection	IP20
Protection class IK (shock resistance)	IK03
Dimmable	No
Mounting type	Surface
Mounting location	Wall; Ceiling
Application environment	Indoor
Mechanically adjustable	No
With light source	Yes
Replaceable light source	No

¹⁾ t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Output current	250mA / 205mA / 165mA / 120 mA
ECG - Output ripple current	< 5 %

Type of Emergency Lighting (EL)	Optional EL unit (battery and controller) for decentral operation available separately
Type of emergency operation test	None
Wattage in emergency operation mode	2 W
Luminous flux in emergency operation mode	200 lm

Standards	CE; CB; UKCA; EAC; ENEC
Luminaire with limited surface temperature, "D sign"	No
Ball shot safe	No
Replaceable light source (EPREL)	Not replaceable

Product remark	Available from September 2026
Added function	MULTI LUMEN; MULTI COLOR; PLUG & UPGRADE

Product code	Packaging unit (Pieces/Unit)	Dimensions (length x width x height)	Gross weight	Volume
4099854894169	Folding box 1	234 mm x 1,225 mm x 85 mm	4095.00 g	24.37 dm³
4099854894176	Shipping box 2	1,252 mm x 259 mm x 195 mm	9770.00 g	63.23 dm³

Product image	Product name	EAN
	DP LN SF CBO DALI CONNECTION KIT	4099854910647

Product name	Product brand	Product component type	GTIN
DR DALI NFC P 42/100-500/220 L OEM	LEDVANCE	driver	4058075851641
DP BATTEN CBO SENSOR LS PD 8 MW INT	LEDVANCE	sensor	4099854521461
DP BATTEN CBO EL CG 200V 3H MT AT	LEDVANCE	el_battery	4099854521430
DP BATTEN CBO EL BAT 6.4V 1.8AH 2WH	LEDVANCE	el_battery	4099854521515
